Development of Multi-Purpose CAD System for Roll Pass of Straight Welded Tubing
-
摘要: 為了提高直縫焊管機組軋輥孔型設計的效率和質量,采用電子計算機輔助設計方法(CAD)進行軋輥孔型設計。該方法僅用10min左右就可完成參數計算、變形圖和輥型簡圖的繪制工作。繪制全套軋輥零件圖亦可從一個月縮短到數小時。文中概述了直縫焊管機組軋輥孔型計算機輔助設計系統(ZHG—CAD)的主要功能和特點。Abstract: Roll pass design of straight welded tubing with CAD method have been developed in order to raise the efficiency and the quality of products. By using this system, calculation of parameter, drawing roll-flowers and drawing roll contouring were accomplished in ten minutes. Design period for a set of spare graphs have been reduced from one month to several hours. The functions and characteristics of the computer-aided design system for roll pass (ZHG-CAD) are described.
-
Key words:
- Computer-Aided Design（CAD） /
- roll pass /
- roll shape
-
