超級絕熱型防火材料的研究進展及其在城市地下空間的應用展望

陳德平; 侯柯屹; 王立佳; 張競揚

doi:10.13374/j.issn2095-9389.2017.06.001

超級絕熱型防火材料的研究進展及其在城市地下空間的應用展望

doi: 10.13374/j.issn2095-9389.2017.06.001

1) 北京科技大學城市地下空間工程北京市重點實驗室, 北京 100083
2) 北京市建筑節能減排協同創新中心, 北京 100044

詳細信息

中圖分類號: TU54
計量
- 文章訪問數: 662
- HTML全文瀏覽量: 268
- PDF下載量: 26
- 被引次數: 0
出版歷程
- 收稿日期: 2017-02-24

Status and development of fire protection materials based on super thermal insulator and their application prospect in urban underground space

1) Beijing Key Laboratory of Urban Underground Space Engineering, University of Science and Technology Beijing, Beijing 100083, China
2) Beijing Energy-Saving and Emission-Reduction Collaborative Innovation Center, Beijing 100044, China

摘要

摘要: 超級絕熱型防火材料,是一種具有納米孔隙結構及超低導熱系數的無機材料,可分為溶膠-凝膠法氣凝膠復合材料和氣相法氧化物納米粉末基材料兩種.其基礎組成氧化物為SiO₂和更高熔點的Al₂O₃、ZrO₂,且研究發現合適的復合組元比單組元在火災溫度下具有更好的耐熱穩定性.紅外遮光劑是顯著降低材料高溫導熱系數的關鍵組分,通過比紅外消光系數測定以及基于Mie散射理論等的數值計算為紅外遮光劑的合理選擇提供了依據.超級絕熱型防火材料,具有高效防火的特點,只要很小的厚度就能達到較高的耐火等級.隨著氣凝膠材料從超臨界干燥向常壓干燥的發展,以及超級絕熱型防火材料總體生產成本的降低,這種材料將在城市地下空間被動防火系統中發揮重要的作用.
- 超級絕熱型防火材料 /
- 氣凝膠 /
- 氣相法氧化物 /
- 紅外遮光劑 /
- 城市地下空間
Abstract: Fire-protective super thermal insulator is an inorganic material with a nanopore structure and super-low thermal conductivity. It can be classified as either a sol-gel aerogel-based composite or a fumed oxide-based composite. The matrix oxides are investigated from SiO₂ to oxides with higher melting temperatures, including Al₂O₃ or ZrO₂. It was found that the complex component oxides with the appropriate ratios exhibit better thermal stability than single oxide when exposed to fire. The infrared opacifier is a key component to this material that can significantly reduce its high-temperature thermal conductivity. The appropriate selection of opacifiers becomes possible by determining the specific infrared extinction coefficient and performing a numerical calculation based on Mie scattering theory. This fire protection material has high fireproof efficiency while also being very thin and is rated as having high fire resistance. With the development of ambient pressure drying for aerogel-based composite from supercritical drying, this fire protection material can be manufactured at low overall cost and will play an important role in passive fire protection systems in urban underground spaces.
- fire protection material based on super-thermal insulator /
- aerogel /
- fumed oxide /
- infrared opacifier /
- urban underground space

HTML全文

參考文獻(44)

[1]	Broere W. Urban underground space:solving the problems of today's cities. Tunnelling Underground Space Technol, 2016, 55:245
[3]	Zhao J W, Peng F L, Wang T Q, et al. Advances in master planning of urban underground space (UUS) in China. Tunnelling Underground Space Technol, 2016, 55:290
[8]	Beard A, Carvel R. The Handbook of Tunnel Fire Safety. London:Thomas Telford, 2005
[10]	Hunt A J. Aerogel-a transparent, porous superinsulator//Materials:Performance and Prevention of Deficiencies and Failures:Proceedings of the Materials Engineering Congress. Atlanta, 1992:398
[11]	Lysenko V, Roussel P, Remaki B, et al. Study of nano-porous silicon with low thermal conductivity as thermal insulating material. J Porous Mater, 2000, 7(1):177
[14]	Kistler S S. Coherent expanded aerogels and jellies. Nature, 1931, 127(3211):741
[15]	Koebel M, Rigacci A, Achard P. Aerogel-based thermal superinsulation:an overview. J Sol-Gel Sci Technol, 2012, 63(3):315
[16]	Wakili K G, Remhof A. Reaction of aerogel containing ceramic fibre insulation to fire exposure. Fire Mater, 2017, 41(1):29
[17]	Saliger R, Heinrich T, Gleissner T, et al. Sintering behaviour of alumina-modified silica aerogels. J Non-Cryst Solids, 1995, 186:113
[19]	Komarneni S, Roy R, Selvaraj U, et al. Nanocomposite aerogels:the SiO₂-Al₂O₃ system. J Mater Res, 1993, 8(12):3163
[20]	Aravind P R, Mukundan P, Pillai P K, et al. Mesoporous silicaalumina aerogels with high thermal pore stability through hybrid sol-gel route followed by subcritical drying. Microporous Mesoporous Mater, 2006, 96(1-3):14
[21]	Levin I, Brandon D. Metastable alumina polymorphs:crystal structures and transition sequences. J Am Ceram Soc, 1998, 81(8):1995
[22]	Zu G Q, Shen J, Wei X Q, et al. Preparation and characterization of monolithic alumina aerogels. J Non-Cryst Solids, 2011, 357(15):2903
[23]	Keysar S, Shter G E, Hazan Y D, et al. Heat treatment of alumina aerogels. Chem Mater, 1997, 9(11):2464
[24]	Mizushima Y, Hori M. Preparation of heat-resistant alumina aerogels. J Mater Res, 1993, 8(11):2993
[26]	Wang Q P, Li X L, Fen W P, et al. Synthesis of crack-free monolithic ZrO 2, aerogel modified by SiO₂. J Porous Mater, 2014, 21(2):127
[30]	White S, Rasky D, Herlth P. Tough, lightweight, superinsulating aerogel/tile composites have potential industrial applications. Mater Technol,1999, 14(1):13
[34]	He J, Li X L, Su D, et al. High-strength mullite fibers reinforced ZrO 2-SiO₂ aerogels fabricated by rapid gel method. J Mater Sci, 2015, 50(22):7488
[36]	Sheng C, Yu Y, Yu Y, et al. Microstructure and thermal characterization of multilayer insulation materials based on silica aerogels. J Inorg Mater, 2013, 28(7):790
[38]	Wei G S, Zhang X X, Yu F. Effective thermal conductivity analysis of xonotlite-aerogel composite insulation material. J Therm Sci, 2009, 18(2):142
[39]	Parmenter K E, Milstein F. Mechanical properties of silica aerogels. J Non-Cryst Solids, 1998, 223(3):179
[40]	Liao Y D, Wu H J, Ding Y F, et al. Engineering thermal and mechanical properties of flexible fiber-reinforced aerogel composites. J Sol-Gel Sci Technol, 2012, 63(3):445
[41]	Nelson R T. Effects of Pressure, Temperature and Gel Thickness on the Kinetics of Supercritical CO₂ Drying of Silica Alcogel[Dissertation]. Massachusetts:Tufts University, 2014
[42]	Yorov K E, Sipyagina N A, Baranchikov A E, et al. SiO₂-TiO₂ binary aerogels:synthesis in new supercritical fluids and study of thermal stability. Russian J Inorg Chem, 2016, 61(11):1339
[43]	Widipedia. Critical Point (thermaodynamics),[2017-02-24]. https://en.wikipedia.org/wiki/Critical_point_%28thermodynamics%29
[44]	Rao A V, Pajonk G M, Bhagat S D, et al. Comparative studies on the surface chemical modification of silica aerogels based on various organosilane compounds of the type R_nSiX_4-n. J NonCryst Solids, 2004, 350:216
[45]	Land V D, Harris T M, Teeters D C. Processing of low-density silica gel by critical point drying or ambient pressure drying. J Non-Cryst Solids, 2001, 283(1-3):11
[47]	Abe H, Abe I, Sato K, et al. Dry powder processing of fibrous fumed silica compacts for thermal insulation. J Am Ceram Soc, 2005, 88(5):1359
[49]	Mortimer M D, Cawley A J, Matthews T M. Microporous Thermal Insulation Material:United States Patent, 20070003751.2007-1-4
[52]	STM International. Standard Specification for Microporous Thermal Insulation (2014)[2017-02-22]. https://compass.astm.org/download/C1676C1676M.798.pdf
[56]	Boes U R, Ortiz L, Roderick K, et al. Method of Compacting A Fumed Metal Oxide-Containing Composition:United States Patent, 6099749.2000-8-8
[57]	McWilliams J A, Morgan D E, Jackson J D J. Method of Manufacturing A Microporous Thermally Insulating Roof:United States Patent, 4925584.1990-5-15
[58]	Gliem S, Kleinschmit P, Schwarz R. Process for the Production of Binder-Free Press-Molded Heat-Insulating Parts:United States Patent, 4529532.1985-7-16
[59]	Kratel G, Katzer H. Shaped Heat-Insulating Body and Process of Making the Same:United States Patent, 4985163.1991-1-15
[60]	Naito M, Kondo A, Yokoyama T. Applications of comminution techniques for the surface modification of powder materials. Iron Steel Inst Jpn Int, 1993, 33(9):915
[61]	Naito M, Abe H, Nogi K, et al. Method and Apparatus for Processing Powder and Method of Manufacturing Porous Granulated Substance:United States Patent, 20070228201.2007-10-4
[68]	Çengel Y A. Heat Transfer:A Practical Approach. 2nd Ed. New York:MacGraw-Hill, 2003
[69]	Kuhn J, Gleissner T, Arduini-Schuster M C, et al. Integration of mineral powders into SiO₂ aerogels. J Non-Cryst Solids, 1995, 186:291
[71]	Lee D, Stevens P C, Zeng S Q, et al. Thermal characterization of carbon-opacified silica aerogels. J Non-Cryst Solids, 1995, 186:285
[72]	Wang J, Kuhn J, Lu X. Monolithic silica aerogel insulation doped with TiO₂ powder and ceramic fibers. J Non-Cryst Solids, 1995, 186:296
[76]	Zhao J J, Duan Y Y, Wang X D, et al. Optical and radiative properties of infrared opacifier particles loaded in silica aerogels for high temperature thermal insulation. Int J Therm Sci, 2013, 70:54
[77]	Wang X D, Sun D, Duan Y Y, et al. Radiative characteristics of opacifier-loaded silica aerogel composites. J Non-Cryst Solids, 2013, 375:31
[78]	Xie T, He Y L, Hu Z J. Theoretical study on thermal conductivities of silica aerogel composite insulating material. Int J Heat Mass Transfer, 2013, 58(1-2):540
[80]	Feng J P, Chen D P, Ni W, et al. Study of IR absorption properties of fumed silica-opacifier composites. J Non-Cryst Solids, 2010, 356(9-10):480
